Honeywell HERMetic UTImeter GTex 2000 – Portable Gas-Tight Tank Gauging & Ullage Measurement System
Honeywell HERMetic UTImeter GTex 2000 is a precision-engineered portable gas-tight tank gauging system designed for accurate ullage, temperature, oil-water interface, and liquid level measurement in petroleum, chemical, marine, and industrial tank applications. Developed for closed and restricted tank gauging operations, the HERMetic UTImeter GTex 2000 provides reliable measurement performance while helping prevent vapour release during tank measurement activities.
The system combines an advanced ultrasonic level sensor, RTD temperature sensor, conductivity-based oil-water interface detection, and graduated stainless-steel measuring tape in a compact portable instrument. It is suitable for petroleum terminals, refineries, tank farms, chemical facilities, marine applications, custody transfer operations, inventory measurement, and tank gauging verification.
Core Working Principle
The Honeywell HERMetic UTImeter GTex 2000 operates by connecting the electronic gauging instrument to a suitable HERMetic vapour control valve installed on the tank. The sensing probe is lowered through the closed gauging connection, allowing measurement to be performed while maintaining controlled tank conditions.
The ultrasonic sensing system detects the liquid surface to determine ullage, while the integrated RTD sensor measures product temperature.
The conductivity sensing element identifies the oil-water interface, enabling operators to determine the presence and level of free water beneath the stored product. The instrument can also be used for manual dip and datum plate detection, providing additional tank measurement information when required.
The measured information is presented through the instrument’s digital display while the graduated tape provides an accurate physical measurement reference.
The system provides ullage and interface accuracy of ±2 mm, tape accuracy of ±1.5 mm per 30 m, and temperature accuracy of ±0.1°C from 0°C to 70°C, making it suitable for precise tank measurement applications.
Key Benefits
- High-Accuracy Ullage Measurement
- Reliable Oil-Water Interface Detection
- Precise Product Temperature Measurement
- Gas-Tight Closed Tank Gauging
- Suitable for Open & Restricted Tank Gauging Applications
- Helps Minimize Vapour Release During Measurement
- Suitable for Petroleum, Chemical & Marine Applications
- Supports Custody Transfer & Inventory Measurement
- Compact and Rugged Construction for Industrial Environments
- Modular Design for Simplified Maintenance
- Suitable for Tank Gauge Verification & Measurement Control
Intelligent Control for Operators
- Clear Digital Display: The 8-character backlit LCD provides operators with clear measurement information during tank gauging activities.
- Accurate Multi-Parameter Measurement: The instrument combines ullage, temperature, and oil-water interface measurement within one portable tank gauging device.
- Gas-Tight Operation: The GTex 2000 is designed for closed tank gauging through a suitable HERMetic vapour control valve, helping operators perform measurements while controlling vapour release.
- Audible & Visual Detection: Audible and visual indications assist operators in identifying the liquid surface and oil-water interface during measurement operations.
- Flexible Temperature Configuration: Temperature can be displayed in °C or °F, with selectable measurement resolution of 0.01°C or 0.1°C.
- Reference Height Measurement: The sensing probe can be used for manual dip and datum plate detection, supporting reference-height and tank measurement verification.
Get in Touch
Looking for a reliable Honeywell HERMetic UTImeter GTex 2000 supplier for your marine vessel, petroleum terminal, refinery, chemical facility, or tank farm?
Contact Swift Marine Tech Service for HERMetic UTImeter GTex 2000 supply, spare parts, calibration support, technical consultation, maintenance assistance, and worldwide delivery.
Our technical team can assist with selecting the appropriate GTex 2000 configuration, tape length, sensing probe, vapour control valve connection, replacement components, and accessories according to your application requirements.
Honeywell HERMetic UTImeter GTex 2000: Advanced Gas-Tight Portable Tank Measurement
The Honeywell HERMetic UTImeter GTex 2000 is a professional portable electronic tank gauging instrument designed for measuring liquid levels and product conditions in petroleum and chemical storage tanks where closed or gas-tight gauging procedures are required.
By combining several measurement functions into one portable device, the GTex 2000 enables operators to perform accurate ullage measurement, temperature measurement, and oil-water interface detection without requiring separate instruments for each measurement task.
The system is particularly suitable for tank inventory control, custody transfer measurement, free-water detection, tank calibration verification, and automatic tank gauge validation. Its combination of electronic sensing technology and graduated measuring tape provides operators with accurate and repeatable tank measurement data.
The HERMetic UTImeter GTex 2000 is designed for use with appropriate HERMetic vapour control valves, allowing operators to perform tank measurements while maintaining a controlled connection with the tank. This makes the instrument suitable for applications where minimizing vapour release and maintaining safe gauging conditions are important.
The standard probe incorporates an ultrasonic liquid-level sensor, RTD temperature sensor, and conductivity electrode for comprehensive liquid measurement. The ultrasonic system detects the product surface, the RTD measures temperature, and the conductivity electrode identifies the oil-water interface.
For applications involving different product characteristics, the HERMetic range provides suitable configurations and probe options. The GTex 2000 can be selected according to the measurement requirements, tank configuration, product characteristics, and required gauging connection.
The instrument incorporates a rugged stainless-steel measuring tape, electronic sensing assembly, backlit LCD display, audible and visual indications, and modular components designed for demanding industrial and marine environments. The modular construction also supports efficient replacement of serviceable components.
The Honeywell HERMetic UTImeter GTex 2000 is widely applicable to oil terminals, petroleum storage tanks, chemical storage facilities, refineries, tank farms, marine cargo operations, and industrial liquid storage facilities where dependable closed manual tank measurement is required.
For organizations requiring accurate and controlled tank measurement, the GTex 2000 provides a practical solution for monitoring liquid level, temperature, free-water conditions, and tank reference measurements while supporting efficient tank inspection and inventory management procedures.
Regular inspection, cleaning, and maintenance of the measuring tape, sensing probe, battery, seals, vapour control connection, and associated components are recommended to maintain measurement reliability. Replacement parts should be selected according to the specific HERMetic UTImeter GTex 2000 configuration to ensure correct operation and compatibility.
